Portable Oil Particle Counter Model LPC-P3

DescriptionLPC-P2 portable oil particle counter is an instrument specially developed for the detection of pollution levels in oil based on national and international standards such as GB/T18854-2002 (ISO11171-1999). Suitable for hydraulic oil, lubricating oil, rock shale oil, transformer oil (insulating oil), turbine oil (turbine oil), gear oil, engine oil, aviation kerosene, water-based hydraulic oil, phosphate ester oil, etc. Laboratory contamination testing. It can also be installed on various hydraulic transmissions, oil filters, washing machines, and test benches to realize on-line detection of system oil cleanliness. Can be widely used in aerospace, power, petroleum, chemical, transportation, port, metallurgy, machinery, automobile manufacturing and other fields.

Features1. The photoresistance (shading) method test principle specified by the International Hydraulic Standards Committee
2. High-precision laser sensor, wide test range, stable performance, low noise and high resolution
3. High-precision metering pump sampling method, adjustable sampling speed, high sampling volume accuracy
4. The pipeline uses 316L and PTFE materials to meet the detection of various organic solvents and oil products
5. For laboratory or field measurement, optional pressure reducing device for online high pressure measurement
6. It can be connected to the pressure chamber to form positive / negative pressure to achieve the detection of high viscosity samples and sample degassing
7. Can use standard sampling bottles, sampling cups and other sampling containers, or directly connect to the hydraulic system for online testing to meet the testing requirements of different industries
8. Built-in multiple calibration curves, compatible with all common standards at home and abroad for calibration
9. Built-in GJB-420A, GJB-420B, NAS1638, ISO4406, SAE4059E, and ГOCT17216 and other commonly used standards, support custom standard tests, and set the required standards according to customer needs
10. 1000 particle size channels can be set to facilitate particle size analysis
11. Built-in data analysis system, can automatically determine the sample level according to the standard, with automatic data processing and printing functions
12. Color touch screen operation, Chinese input, with preset, input, modification, storage functions, easy and fast operation
13. With RS232 interface, it can be connected to a computer or laboratory platform for data processing, and USB can also be used for data storage
14. Built-in lithium battery, suitable for field work, can be used without external power supply
15. Embedded design, high strength shell, easy to carry, suitable for all kinds of construction machinery

Technical Index1. Light source: semiconductor laser
2. Particle size range: 0.8-600um (depending on different sensors)
3. Detection channel: 8 channels, arbitrarily set particle size
4. Sampling volume: 0.2-1000ml
5. Sampling accuracy: better than ± 1%
6. Sampling speed: 5-80mL / min
7. Counting accuracy: ± 10%
8. Resolution: ≤10%
9. Repeatability: RSD <2%
10. Limit coincidence error: 1200-40000 capsules / mL
11. Pressure range: low pressure 0-6bar, high pressure 5-420bar (optional pressure reducing valve)
12. Viscosity range: ≤350cSt
13. Power supply: AC100-240V, 50 / 60Hz
14. Battery capacity: 5200mAh
15. Battery running time: 6-8 hours
16. Dimensions: 410 × 320 × 165mm
17. Weight: 8.5kg
