Aging Transformer Oil Regeneration Vacuum Dehydration Machine, Used Insulating Oil Recycling Plant ZYD-II-150(9000LPH)

Application

REXON Aging Transformer Oil Regeneration Vacuum Dehydration Machine, Used Insulating Oil Recycling Plant ZYD-II-150(9000LPH) is applied to regenerate various of unqualified insulation oils including aging transformer oil specially for the power which is above 110KV, mutual inductor oil, switch oil and so on. It takes vacuum dehydration and degassing system, multistage filtering system, heating system, PLC auto control system, eletrical system with protection devices, etc, and fuller's earth filter groups to regeneration aging old transformer oil to be new. Fuller’s earth treatment will remove both acid and impurities in the oil. This process corrects the acid number as well as the colour. Reclamation of oil with a high acid content consists of needs fuller’s earth treatment.The oil is regenerated by passing through a Fuller’s Earth filter medium for molecular filtration.Contaminants and oil degradation products are trapped in the granules of the sorbent. After sorbent saturation, the ZYD-II unit automoatically switches to sorbent reactivation mode to remove contaminants from the sorbent into a special collector and charcoal filter. Advantages

Besides the Double-Stage High-Efficiency Vacuum Transformer Oil purifier's function of dehydrating oil, degassing and eliminating impurities from oil, this High Vacuum Transformer Oil Regeneration System, Transformer Oil Recycling Purifier ZYD-II machine can regenerate the seriously deteriorated oil by removing the polarity materials, such as the deep oxides, free carbon, acidity in the oil effectively. It can make the seriously deteriorated oil reach to the normal index like anti-oxides, acid- alkali water-solubility. Also it can inject the insulating oil into the transformers on-line. After the oil regeneration processing treatment, the transformer oil will become new, qualified and fresh to use.

Technical Parameters
